Traction and Eco-eriendly Vehicle Batteries

Features

Use brand new original Grade A power LiFePO₄ battery cells
Equipped with 2025-AI intelligent software-based Battery Management System (BMS)
Supports communication and parallel connection of up to 5 battery packs – data viewable on a single display
Optional self-developed 4.3-inch color display and low-temperature heating function
Precise temperature monitoring & millivolt-level voltage sampling
BMS supports RS485 or CAN communication protocols
Easy installation, easy operation, easy maintenance
Multi-layer insulation material wrapping design for enhanced safety
Adopts 4kW automotive-grade laser welding busbar technology – over 200A continuous stable current capability
Features short-circuit protection, over-charge protection, over-discharge protection, high-temperature protection, and low-temperature protection
Specially designed arched busbar eliminates expansion stress – improves safety and extends service life
Mini-program/App smart 4G remote and Bluetooth reading of battery information – supports remote locking

Power supply parameter table
Product Model	51.2V100Ah	51.2V200Ah	64V100Ah	64V200Ah	76.8V100Ah	76.8V200Ah	96V100Ah	96V200Ah
Rated Energy	5120wh	10240wh	6400wh	12800wh	7680wh	15360wh	9600wh	19200wh
Cell Type	LFP(LiFePO4)
Nominal Voltage	51.2V		64.0V		76.8V		96V
Operating Voltage	43.2~57.6V		54.0 ~ 72.0V		64.8 ~ 86.4V		81.0~108.0V
Charging Voltage	57.6V(CC/CV)		72V (CC/CV)		86.4 (CC/CV)		108 (CC/CV)
Charging Current (A)	≤50	≤100	≤50	≤100	≤100	≤100	≤50	≤100
Discharging Current (A)	≤100	≤100	≤100	≤100	≤100	≤100	≤50	≤100
Operating Temperature (℃)	Charging:0~+55℃, Discharging:-20~+55℃
Communication Method	RS485、CAN
Storage Temperature	>1 month:0~+35℃, ≤1 month :-20~+45℃
Relative Humidity	≤90%
Shipment Capacity	30%-50%
Weight	40kg	75kg	50kg	90kg	58kg	120kg	75kg	150kg
Dimensions	For detailed consultation, we accept free customization!
