Traction and Eco-eriendly Vehicle Batteries
Traction and eco-friendly vehicle LiFePO4 batteries designed for electric vehicles, sightseeing cars, forklifts, golf carts and AGV robots. Available in multiple voltage and capacity configurations from 51.2V to 96V, with energy capacity up to 19.2kWh. Equipped with high-quality LiFePO4 cells and intelligent BMS protection, supporting RS485 and CAN communication. Features safe operation, long cycle life and customizable specifications for various industrial and commercial vehicle applications.
•High-Performance LiFePO4 Battery Technology — Uses high-quality lithium iron phosphate cells with excellent safety, thermal stability and long cycle life for reliable vehicle power applications.
•Multiple Voltage & Capacity Options — Available in 51.2V, 64V, 76.8V and 96V configurations with capacity options up to 19.2kWh to meet different vehicle power requirements.
•Intelligent BMS Protection System — Integrated battery management system provides protection against over-charge, over-discharge, over-current, short circuit and temperature abnormalities.
•Wide Vehicle Compatibility — Designed for electric vehicles, sightseeing cars, forklifts, golf carts, AGV robots and other industrial traction applications.
•Reliable Communication Interface — Supports RS485 and CAN communication for integration with vehicle control systems, monitoring platforms and energy management systems.
•High Safety & Long Cycle Life — Delivers stable performance with excellent durability, reducing maintenance requirements and extending battery service life.
•Flexible Customization Solutions — Supports customized voltage, capacity, dimensions and battery configurations to meet different application requirements.
•Advanced Monitoring Functions — Supports optional APP, 4G remote monitoring, display solutions and intelligent management features for convenient operation.
Features
- Use brand new original Grade A power LiFePO₄ battery cells
- Equipped with 2025-AI intelligent software-based Battery Management System (BMS)
- Supports communication and parallel connection of up to 5 battery packs – data viewable on a single display
- Optional self-developed 4.3-inch color display and low-temperature heating function
- Precise temperature monitoring & millivolt-level voltage sampling
- BMS supports RS485 or CAN communication protocols
- Easy installation, easy operation, easy maintenance
- Multi-layer insulation material wrapping design for enhanced safety
- Adopts 4kW automotive-grade laser welding busbar technology – over 200A continuous stable current capability
- Features short-circuit protection, over-charge protection, over-discharge protection, high-temperature protection, and low-temperature protection
- Specially designed arched busbar eliminates expansion stress – improves safety and extends service life
- Mini-program/App smart 4G remote and Bluetooth reading of battery information – supports remote locking
Technical Parameter
| Power supply parameter table | ||||||||
| Product Model | 51.2V100Ah | 51.2V200Ah | 64V100Ah | 64V200Ah | 76.8V100Ah | 76.8V200Ah | 96V100Ah | 96V200Ah |
| Rated Energy | 5120wh | 10240wh | 6400wh | 12800wh | 7680wh | 15360wh | 9600wh | 19200wh |
| Cell Type | LFP(LiFePO4) | |||||||
| Nominal Voltage | 51.2V | 64.0V | 76.8V | 96V | ||||
| Operating Voltage | 43.2~57.6V | 54.0 ~ 72.0V | 64.8 ~ 86.4V | 81.0~108.0V | ||||
| Charging Voltage | 57.6V(CC/CV) | 72V (CC/CV) | 86.4 (CC/CV) | 108 (CC/CV) | ||||
| Charging Current (A) | ≤50 | ≤100 | ≤50 | ≤100 | ≤100 | ≤100 | ≤50 | ≤100 |
| Discharging Current (A) | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤50 | ≤100 |
| Operating Temperature (℃) | Charging:0~+55℃, Discharging:-20~+55℃ | |||||||
| Communication Method | RS485、CAN | |||||||
| Storage Temperature | >1 month:0~+35℃, ≤1 month :-20~+45℃ | |||||||
| Relative Humidity | ≤90% | |||||||
| Shipment Capacity | 30%-50% | |||||||
| Weight | 40kg | 75kg | 50kg | 90kg | 58kg | 120kg | 75kg | 150kg |
| Dimensions | For detailed consultation, we accept free customization! | |||||||
